MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard

Save: 3,300৳

MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard

0 reviews - Write a review

Price: 26,200৳

Regular Price: 29,500৳

Stock : In Stock

Brand:

Model: MSI PRO B860M-A WIFI

Model: MSI PRO B860M-A WIFI
Supports Intel® Core™ Ultra Processors
Up to DDR5 8600+ MT/s (OC)
5G LAN & Wi-Fi 7

26,200৳

Cash Discount Price

Online / Cash Payment

5,673৳/month

Regular Price: 29,500৳

EMI Starting from 5,673৳/month.
Click here to check EMI Policy

Qty

Add to Cart

Buy Now

Add to Wish List Add to Compare

অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে। হটলাইনঃ 09644-217088

Custom Tabs

NEW! Since Journal 3.2, the much improved T.A.B (Tabs Accordion Blocks) system supports the page builder inside the tab content. Unlimited Blocks, Tabs or Accordions with any HTML content or the builder interface (supporting custom rows/columns/modules) can be assigned to any individual product or to certain groups of products, like entire categories, brands, products with specific options, attributes, price range, etc.

You can indicate any criteria via the advanced product assignment mechanism and only those products matching your criteria will display the modules.

Also, any module can be selectively activated per device (desktop/tablet/phone), customer login status and other criteria. Imagine the possibilities.

Description

Specification

Motherboard Specification
Chipset	INTEL B860
Form Factor	Micro- ATX
Audio	Realtek® ALC897 Codec 7.1-Channel High Definition Audio
Socket	LGA 1851
Memory Specification
Memory Capacity	4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support 8600 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 8600+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 4800+ MT/s • 2DPC 2R Max speed up to 4800+ MT/s Supports Intel® POR Speed and JEDEC Speed Supports Memory Overclocking and Intel® XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM
Network & Wireless
Wi-Fi	Intel® Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
LAN	Realtek® 8126 5Gbps LAN
Supports
Supported CPU	Supports Intel® Core™ Ultra Processors (Series 2)
Connectors
USB	2x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 1x USB 5Gbps Type C (Rear) 4x USB 5Gbps Type A (Front) 1x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Front)
HDMI	1x HDMI Support HDMI™ 2.1, maximum resolution of 4K 60Hz*
Display Port	1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* 1x Type-C DisplayPort Thunderbolt™ 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz*
Ports & Slots
Slots	4x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset)
Internal I/O Ports	1x Thunderbolt5 card connector(JTBT5, support RTD3) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports
PCI-E	4x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset)
Warranty Information
Warranty	3 Years

MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard

The MSI PRO B860M-A WIFI LGA 1851 Micro ATX Motherboard is a feature-packed solution for modern PC enthusiasts. Built with the Intel B860 chipset, it supports the latest Intel® Core™ Ultra processors (Series 2) and uses the LGA 1851 socket, ensuring cutting-edge performance. This Micro-ATX motherboard is equipped with four DDR5 UDIMM slots, supporting up to 256GB of memory with overclocking capabilities up to 8600 MT/s, making it ideal for high-speed multitasking and gaming.

Networking is seamless with Intel® Wi-Fi 7, offering speeds up to 5.8Gbps and support for 2.4GHz, 5GHz, and 6GHz bands. Additionally, the Realtek® 8126 5Gbps LAN ensures stable wired connections. The board includes multiple USB options, including USB 10Gbps Type-A and Type-C ports, as well as Thunderbolt™ 4 with DisplayPort 2.1 support, offering resolutions up to 8K at 60Hz.

The MSI PRO B860M-A supports multiple PCI-E slots, including a PCIe 5.0 slot for powerful GPUs. It also features advanced audio with Realtek® ALC897 Codec for an immersive 7.1-channel sound experience. With robust connectivity, impressive overclocking potential, and a 3-year warranty, this motherboard is a top choice for both professional and gaming setups.

Reviews

What is the price of MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard in Bangladesh?

The latest price of MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard in Bangladesh is 26,200৳ You can buy the MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard at best price from our website or visit any of our showrooms.
