Intel 11th Gen Core i5-11500 Rocket Lake Processor

Intel 11th Gen Core i5-11500 Rocket Lake Processor

This Intel Core i5-11500 11th Gen Processor comes with Intel UHD Graphics 750. This new 11th gen Rocket Lake microarchitecture is manufactured with the 14nm process that comes with six cores and twelve threads. As this chip is updated to the latest BIOS revision, it nicely fits into any Intel 400 and 500 series motherboards. Focusing on this, all the major motherboard manufacturers have already started BIOS updates for their 400 and 500 series lineup. These Processors also support 64-bit computing on Intel architecture require an Intel x86-64 (64 bit) architecture-enabled BIOS.

Core Benefits of the Processor

Intel 11th Generation Core i5-11500 Processor having the base frequency of 2.70 GHz that can be reached as max turbo frequency at 4.60 GHz. The processor has a compatibility socket of LGA 1200 that is supported by 400 and 500 series Intel motherboards. It has a SmartCache of 12 MB containing 6 cores and 12 threads. With a bus speed of 8 GT/s, it has thermal design power (TDP) rating of 65W. This latest microchip has few expansion options such as 4.0 PCI express revision having configured up to up to 1x16+1x4, 2x8+1x4, 1x8+3x4 and a maximum of 20 lanes. Considering the memory this processor has a dual-channel of max 128GB of the size that supports up to DDR4-3200 bus speed.

Brand	Intel
Model	Core i5-11500
Base Frequency	2.70 GHz
Maximum Turbo Frequency	4.60 GHz
Cache	12MB
Cores	6
Threads	12
Default TDP	65 W
Maximum Size	128 GB
Maximum Speed	3200MHz
Type	DDR4
Max Number of Channels	2
Processor Graphics	Intel UHD Graphics 750
Base Frequency	350 MHz
Max Dynamic Frequency	1.30 GHz
Max Video Memory	64 GB
Max Resolution	4K Support: Yes, at 60Hz Max Resolution (HDMI): 4096x2160@60Hz Max Resolution (DP): 5120 x 3200 @60Hz Max Resolution (eDP - Integrated Flat Panel): 5120 x 3200 @60Hz
Core Count	32
Manufacturing Warranty	3 Years (No Warranty for Fan or Cooler)
