Intel Core i5 10400 10th Gen Processor

Intel 10th Gen Core i5-10400 Processor

This i5-10400 Processor comes with an Intel UHD Graphics 630 graphics. This new 10th gen Comet Lake microarchitecture is manufactured with the 14nm process that comes with six cores but lacks in HyperThreading. As this chip is updated to the latest BIOS revision, it nicely fits into any Intel 400-series motherboard. Focusing on this, all the major motherboard manufacturers have already started BIOS updates for their 400-series lineup. These Processors also support 64-bit computing on Intel architecture require an Intel 64 architecture-enabled BIOS.

Core Benefits of the Processor

Intel 10th Generation Core i5-10400 Processor having the base frequency of 2.90 GHz that can be reached as max turbo frequency at 4.30 GHz. It has the SmartCache of 12 MB containing 6 cores and 12 threads. With the bus speed of 8 GT/s DMI3, it has thermal design power (TDP) rating of 65W. This latest microchip has few expansion options such 3.0 PCI express revision having configured up to 1x16, 2x8, 1x8+2x4, and maximum 16 lanes. Considering the memory this processor has dual-channel of max 128GB of the size that supports up to DDR4-2666 bus speed.

Brand	Intel
Model	i5-10400
Base Frequency	2.90 GHz
Maximum Turbo Frequency	4.30 GHz
Cache	12 MB SmartCache
Cores	6
Threads	12
Default TDP	65 W
Supported Technologies	Sockets Supported: FCLGA1200
Maximum Size	128 GB
Maximum Speed	2666
Type	DDR4
Max Number of Channels	2
Processor Graphics	Intel UHD Graphics 630
Base Frequency	350 MHz
Max Dynamic Frequency	1.10 GHz
Max Video Memory	64 GB
Max Resolution	Max Resolution (HDMI 1.4): 4096x2304@30Hz Max Resolution (DP)‡: 4096x2304@60Hz Max Resolution (eDP - Integrated Flat Panel): 4096x2304@60Hz
Core Count	6
Manufacturing Warranty	03 Years Warranty (No Warranty for Fan or Cooler)
