BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard
Key Features
- Model: B550MXC PRO
- Supported CPU: Ryzen 3rd Gen and 4th Gen processors
- Supported RAM: 2x DIMM, DDR4 4933+(OC)
- Graphics Output: 1 x HDMI
- Features: Supports WiFi 6 module
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে। হটলাইনঃ 09644-217088
NEW! Since Journal 3.2, the much improved T.A.B (Tabs Accordion Blocks) system supports the page builder inside the tab content. Unlimited Blocks, Tabs or Accordions with any HTML content or the builder interface (supporting custom rows/columns/modules) can be assigned to any individual product or to certain groups of products, like entire categories, brands, products with specific options, attributes, price range, etc.
You can indicate any criteria via the advanced product assignment mechanism and only those products matching your criteria will display the modules.
Also, any module can be selectively activated per device (desktop/tablet/phone), customer login status and other criteria. Imagine the possibilities.
BIOSTAR B550MXC PRO Micro ATX Motherboard
The BIOSTAR B550MXC PRO is a feature-rich micro ATX motherboard designed to support the latest AMD Ryzen processors, providing a solid foundation for high-performance computing systems. With its compatibility for both 3rd and 4th Gen AMD Ryzen CPUs, including Matisse, Renoir, Vermeer, and Cezanne, this motherboard ensures excellent future-proofing with the capability to support upcoming AMD Ryzen processors via a BIOS update.The motherboard boasts a robust AMD B550 chipset, which facilitates a powerful computing experience while maintaining energy efficiency. Its Micro ATX form factor makes it ideal for compact builds without compromising on functionality and expandability.Memory support on the B550MXC PRO is impressive, accommodating up to 128GB of DDR4 RAM across four DIMM slots. Users can opt for varying speeds, ranging from 1866MHz up to an impressive 4533MHz (when overclocked), enabling smooth multitasking and seamless performance during resource-intensive tasks.For graphics, the motherboard leverages the CPU's integrated graphics capabilities, supporting DirectX 12 and HDCP for modern visual experiences. Gamers and content creators will appreciate the support for multiple display outputs, including an HDMI port and a VGA port.Storage options on the B550MXC PRO are extensive, featuring two M.2 sockets and eight SATA III (6Gb/s) ports. These M.2 sockets can accommodate different SSD types, including PCIe 4.0 x4 and PCIe 3.0 x4 drives, offering blazing-fast data transfer speeds for lightning-quick boot times and application loading.Connectivity is well-covered with USB ports, including a USB 3.2 (Gen2) Type-C port, USB 3.2 (Gen2) port, and multiple USB 3.2 (Gen1) and USB 2.0 ports. The Realtek ALC897 audio chipset delivers a high-definition audio experience with 7.1 channels and a Hi-Fi front output.The B550MXC PRO comes equipped with numerous I/O ports and connectors to meet diverse needs. It features multiple PCIe slots for expansion cards, as well as headers for USB, fans, and LED accessories, giving users the flexibility to customize and enhance their system as desired.Furthermore, the motherboard includes convenient features like BullGuard, VIVID LED DJ, BIO-FLASHER, A.I FAN, and LED ROCK ZONE, which enhance system monitoring, cooling, and aesthetics.
Specification
Motherboard Features | |
Motherboard Model | B550MXC PRO |
Supported CPU | Socket AM4 support AMD Ryzen™ 3rd Gen (Matisse/ Renoir) and Ryzen™ 4th Gen (Vermeer/ Cezanne) processors Support for future AMD Ryzen processors with BIOS update |
Chipset | AMD B550 |
Form Factor | Micro ATX Form Factor Dimension: 24.4cm x 24.4cm ( W x L ) |
Memory Type | DDR4 |
Memory Slots | 4th Gen AMD Ryzen Processors (Vermeer CPUs/ Cezanne APUs): Supports Dual Channel DDR4 1866/2133/2400/2666/2933/3200/4533(OC) 3rd Gen AMD Ryzen Processors (Matisse CPUs): Supports Dual Channel DDR4 1866/2133/2400/2666/2933/3200/4533(OC) 3rd Gen AMD Ryzen with Radeon Graphics Processors (Renoir APUs): Supports Dual Channel DDR4 1866/2133/2400/2666/2933/3200/4533(OC) 4 x DDR4 DIMM Memory Slot, Max. Supports up to 128 GB Memory Each DIMM supports non-ECC and ECC Un-buffered 8/ 16/ 32 GB DDR4 module |
Graphics | By CPU model Supports DX12 Supports HDCP |
Supported Storage | Total supports 2 x M.2 socket and 8 x SATA III (6Gb/s) ports 1x M.2 (M Key) Socket (M2_PCIEG4_64G_SATA): Supports M.2 Type 2242/ 2260/ 2280 SSD module AMD Ryzen 5000/3000 Series Processors Supports PCIe 4.0 x 4 (64Gb/s) & SATA III (6.0Gb/s) SSD AMD Ryzen 5000 G/4000 G Series Processors Supports PCIe 3.0 x 4 (32Gb/s) & SATA III (6.0Gb/s) SSD AMD B550 Chipset 1x M.2 (M Key) Socket (M2_PCIEG3_32G_SATA): Supports M.2 Type 2280 SSD module Supports PCIe 3.0 x 4 (32Gb/s) & SATA III (6.0Gb/s) SSD 4 x SATA III (6Gb/s) Support AHCI & RAID 0, 1, 5, 10 only for SATA1 ~ SATA4 ports * M.2 (M2_PCIEG4_64G_SATA) Socket: The bandwidth is depended on CPU. Supports PCIe 4.0 x 4 (64Gb/s) speed, which depends only on Ryzen 3rd Gen Matisse & 4th Gen Vermeer. |
Ports & Connectors | |
Audio | Realtek ALC897 7.1 Channels, High Definition Audio, Hi-Fi (Front) 3 x Audio Jack |
HDMI | 1 x HDMI Port |
LAN | Realtek RTL8111H 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability |
USB | 1 x USB 3.2 (Gen2) Type-C port (1 on rear I/O) 1 x USB 3.2 (Gen2) port (1 on rear I/O) 6 x USB 3.2 (Gen1) port (4 on rear I/Os and 2 via internal headers) 6 x USB 2.0 port (2 on rear I/Os and 4 via internal headers) 4 x USB 3.2 (Gen1) Port 2 x USB 2.0 Port 1 x USB 3.2 (Gen2) Type-C port 1 x USB 3.2 (Gen2) port |
Slot | AMD Ryzen 5000/3000 Series Processors 1 x PCIe 4.0 x16 Slot (x16 or x4/x4/x4/x4 mode) or AMD Ryzen 5000 G/4000 G Series Processors 1 x PCIe 3.0 x16 Slot (x16 or x8/x4/x4 mode) AMD B550 Chipset 1 x PCIe 3.0 x16 Slot (x1 mode) 1 x PCIe 3.0 x16 Slot (x1 mode) 1 x PCIe 3.0 x16 Slot (x1 mode) * According to different CPUs will have different speeds. * PCIe 4.0 speed only for AMD Ryzen™ 3rd Gen Matisse and 4th Gen Vermeer CPUs. |
I/O Ports | 8 x SATA III (6.0Gb/s) Connector 1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module 2 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports) 1 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 2 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Internal Stereo Speaker Header 1 x Clear CMOS Header 1 x S/PDIF out Connector 1 x COM Port Header 1 x TPM Header 2 x LED Header (5V) 1 x LED Header (12V) 1 x Debug LED * M.2 (E key) Wi-Fi card is not provided |
VGA | 1 x VGA Port |
Others | Bundled Software: BullGuard 2 x WIFI Antenna Port 1 x PS/2 Keyboard / Mouse Supports Windows 10(64bit) / 11(64bit) 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide 1 x WiFi antenna accessories VIVID LED DJ BIO-FLASHER A.I FAN LED ROCK ZONE |
What is the price of BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard in Bangladesh?
The latest price of BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard in Bangladesh is 11,400৳ You can buy the BIOSTAR B550MXC PRO DDR4 AMD AM4 Micro ATX Motherboard at best price from our website or visit any of our showrooms.
