Asus Pro WS W680-ACE ATX Motherboard

Asus Pro WS W680-ACE ATX Motherboard
Asus Pro WS W680-ACE ATX Motherboard
Asus Pro WS W680-ACE ATX Motherboard
Asus Pro WS W680-ACE ATX Motherboard
Save: 4,850৳
Asus Pro WS W680-ACE ATX Motherboard
Asus Pro WS W680-ACE ATX Motherboard
Asus Pro WS W680-ACE ATX Motherboard
Asus Pro WS W680-ACE ATX Motherboard
Asus Pro WS W680-ACE ATX Motherboard
0 reviews - Write a review
  • Price: 48,500৳
  • Regular Price: 53,350৳
  • Stock : In Stock
  • Brand: Asus
  • Model: Pro WS W680-ACE

    • Key Features

    • Model: Pro WS W680-ACE
    • Supported CPU: 14th, 13th Gen & 12th Gen Processors (LGA1700)
    • Supported Memory: 4 x DIMM, Max. 192GB, DDR5
    • Graphics Output: 1 x DisplayPort, 2 x HDMI, 1 x VGA port
    • Features: 2 x Intel 2.5Gb Ethernet, ASUS LANGuard
    Add to Cart
    Buy Now
    Add to Wish List Add to Compare

    অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে। হটলাইনঃ 09644-217088

    NEW! Since Journal 3.2, the much improved T.A.B (Tabs Accordion Blocks) system supports the page builder inside the tab content. Unlimited Blocks, Tabs or Accordions with any HTML content or the builder interface (supporting custom rows/columns/modules) can be assigned to any individual product or to certain groups of products, like entire categories, brands, products with specific options, attributes, price range, etc.

    You can indicate any criteria via the advanced product assignment mechanism and only those products matching your criteria will display the modules.

    Also, any module can be selectively activated per device (desktop/tablet/phone), customer login status and other criteria. Imagine the possibilities.

    Specification

    Basic Information
    Supported CPU Intel® LGA 1700 socket: Ready for 14th, 13th Gen Intel Core processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors
    Chipset Intel W680 Chipset
    BIOS 256 Mb Flash ROM, UEFI AMI BIOS
    Form Factor ATX Form Factor
    12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
    Audio Realtek 7.1 Surround Sound High Definition Audio CODEC
    - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
    - Supports up to 24-Bit/192 kHz playback"
    Audio Features
    - Audio Shielding
    - Premium audio capacitors
    - Dedicated audio PCB layers
    - Unique de-pop circuit
    Expansion Slots
    PCI Intel® 13th & 12th Gen Processors
    - 2 x PCIe 5.0 x16 slots (support x16 or x8 / x8 mode)
    Intel® W680 Chipset
    - 2 x PCIe 3.0 x16 slots (supports x4 mode)
    - 1 x PCIe 3.0 x1 slot
    M.2 Socket Total supports 3 x M.2 slots
    Memory
    Type DDR5
    Slots 4 x DIMM
    Supported Memory DDR5 ECC and Non-ECC Un-buffered Memory
    Dual Channel Memory Architecture
    Supports Intel Extreme Memory Profile (XMP)
    OptiMem II
    Maximum Memory Max. 192GB
    Graphics
    Graphics supports max. 8K@60Hz as specified in DisplayPort 1.4.
    Supports 4K@60Hz as specified in HDMI 2.1.
    Connector & Ports
    HDMI 2 x HDMI port
    Display Port (s) 1 x DisplayPort
    VGA (s) 1 x VGA port
    USB (s) Rear USB (Total 8 ports)
    - 2 x USB 3.2 Gen 2 ports (1 x Type-A, 1 x Type-C®)
    - 4 x USB 3.2 Gen 1 ports (4 x Type-A)
    - 2 x USB 2.0 ports (2 x Type-A)
    Front USB (Total 7 ports)
    - 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C®)
    - 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
    - 2 x USB 2.0 headers support additional 4 USB 2.0 ports
    LAN Port (s) 2 x Intel 2.5Gb Ethernet
    ASUS LANGuard
    Wireless Communication module M.2 slot only (Key E, CNVi & PCIe)*
    *Wi-Fi module is sold separately.
    Supported Storage Total supports 3 x M.2 slots and 8 x SATA 6Gb/s ports*
    Intel 13th & 12th Gen Processors
    - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
    Intel W680 Chipset
    - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
    - M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
    - 4 x SATA 6Gb/s ports
    - 1 x SlimSAS Slot Support SlimSAS NVMe device (supports PCIe 4.0 x4 mode and up to 4 SATA devices)
    RAID Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10.
    Audio 5 x Audio jacks
    Internal I/O Ports Internal I/O Connectors

    Fan and Cooling related
    1 x 4-pin CPU Fan header
    1 x 4-pin CPU OPT Fan header
    1 x 4-pin W_PUMP+ header
    3 x 4-pin Chassis Fan headers
    Power related
    1 x 24-pin Main Power connector
    1 x 8-pin +12V Power connector
    1 x 4-pin +12V Power connector
    1 x 6-pin PCIe Power connector
    Storage related
    3 x M.2 slots (Key M)
    4 x SATA 6Gb/s ports
    1 x SlimSAS port
    USB
    1 x USB 3.2 Gen 2x2 connector (supports USB Type-C® )
    1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
    2 x USB 2.0 headers support 4 additional USB 2.0 ports
    Miscellaneous
    1 x LPT header
    1 x T-sensor
    1 x Clear CMOS header
    1 x COM Port header
    1 x BMC Header
    1 x Front Panel Audio header (AAFP)
    1 x Start button
    1 x Flexkey button
    1 x 20-3 pin System Panel header with Chassis intrude function
    1 x M.2 slot (Key E)
    1 x LPT_P80 Switch
    1 x Thunderbolt header
    TPM (Trusted Platform Module ) 1 x SPI TPM header (14-1pin)
    Others
    Special Features ASUS 5X PROTECTION III
    - DIGI+ VRM (- Digital power design with DrMOS)
    - ESD Guards
    - LANGuard
    - Overvoltage Protection
    - SafeSlot
    - Stainless-Steel Back I/O
    ASUS Q-Design
    - Q-Code
    - M.2 Q-Latch
    - Q-Connector
    - Q-DIMM
    - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
    - Q-Slot
    ASUS Thermal Solution
    - M.2 heatsink
    - VRM heatsink design
    ASUS EZ DIY
    - CPU Socket lever protector
    - SafeDIMM
    - SafeSlot
    - BIOS FlashBack button
    - BIOS FlashBack LED
    Bespoke Motherboard Design & Business Focused Features
    - 24/7 Reliability
    Bundled Software Intel® vPro support
    ASUS Exclusive Software
    Armoury Crate
    - Fan Xpert 4
    - Power Saving
    ASUS CPU-Z
    Adobe Creative Cloud (Free Trial)
    Norton 360 Deluxe (60 Days Free Trial)
    WinRAR
    IT Management software supported
    - ASUS Control Center Express(ACCE)
    UEFI BIOS
    ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    FlexKey
    Intel® vPro support
    ASUS Exclusive Software
    Armoury Crate
    - Fan Xpert 4
    - Power Saving
    ASUS CPU-Z
    Adobe Creative Cloud (Free Trial)
    Norton 360 Deluxe (60 Days Free Trial)
    WinRAR
    IT Management software supported
    - ASUS Control Center Express(ACCE)
    UEFI BIOS
    ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    FlexKey
    Warranty Information
    Manufacturing Warranty 3 years warranty


    Asus Pro WS W680-ACE ATX Motherboard

    The ASUS Pro WS W680-ACE LGA 1700 ATX Motherboard's powerful performance will boost your productivity and editing skills. With a wide range of connectivity options and different ports, this motherboard provides a solid platform for your production. The Pro WS motherboard is built around Intel's LGA 1700 socket, which allows you to install a range of 12th and 13th Generation Core CPUs. Four DDR5 RAM slots allow you to install up to 192GB of memory, which improves multitasking and rendering speeds. Four SATA III, three M.2 PCIe SSD, and one SlimSAS slot interface can accommodate a wide range of storage devices, allowing for faster data transmission speeds. USB 2.0, 3.2 Gen 1, Gen 2, and Gen 2x2 compatibility is available via back-panel connectors and internal headers, making it suitable for both low-powered devices like keyboards and mice and resource-demanding devices like audio interfaces, external storage arrays, and so on. Dual 2.5 Gigabit Ethernet ports provide teaming capabilities, resulting in faster video uploads to shared NAS folders, cloud storage systems, and other destinations. ASUS Pro WS W680-ACE is intended for professionals in AI training, deep learning, animation, 3D rendering, and media creation. Pro Workstation motherboards are the best alternative for creative workers, since they offer expanded graphics, large storage, amazing connections, and exceptional overall performance and dependability. The Pro WS W680-ACE has centralized administration software, making it an efficient and cost-effective solution for IT managers.

    Write a review

    Please login or register to review

    What is the price of Asus Pro WS W680-ACE ATX Motherboard in Bangladesh?

    The latest price of Asus Pro WS W680-ACE ATX Motherboard in Bangladesh is 48,500৳ You can buy the Asus Pro WS W680-ACE ATX Motherboard at best price from our website or visit any of our showrooms.
