ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard

ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard
0 reviews - Write a review
  • Price: 19,350৳
  • Regular Price: 24,000৳
  • Stock : In Stock
  • Brand: Asus
  • Model: B760M-C-CSM

    • Key Features

    • Model: PRO B760M-C-CSM
    • Supported CPU: 14th 13th Gen & 12th Gen Processors (LGA1700)
    • Supported Memory: 4 x DIMM, Max. 192GB, DDR5 6200(OC)
    • Graphics Output: 2 x DisplayPort, 1 x VGA, 1 x HDMI
    • Features: 1 x Intel 1Gb Ethernet
    Add to Cart
    Buy Now
    Add to Wish List Add to Compare

    অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে। হটলাইনঃ 09644-217088

    NEW! Since Journal 3.2, the much improved T.A.B (Tabs Accordion Blocks) system supports the page builder inside the tab content. Unlimited Blocks, Tabs or Accordions with any HTML content or the builder interface (supporting custom rows/columns/modules) can be assigned to any individual product or to certain groups of products, like entire categories, brands, products with specific options, attributes, price range, etc.

    You can indicate any criteria via the advanced product assignment mechanism and only those products matching your criteria will display the modules.

    Also, any module can be selectively activated per device (desktop/tablet/phone), customer login status and other criteria. Imagine the possibilities.

    ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard

    ASUS PRO B760M-C-CSM Motherboard Specification

    Model PRO B760M-C-CSM
    Brand ASUS
    Supported CPU Intel Socket LGA1700 for 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
    Chipset Intel B760 Chipset
    BIOS 128Mb Flash ROM
    Form Factor mATX Form Factor 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)
    Audio Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback
    PCI Intel 13th & 12th Gen Processors 1 x PCIe 4.0/3.0 x16 slot Intel B760 Chipset 2 x PCIe 3.0 x1 slots
    Type DDR5
    Slots 4 x DIMM
    Supported Memory DDR5 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) Optimem II
    Maximum Memory Max. 192GB
    Graphics 2 x DisplayPort** 1 x VGA port 1 x HDMI port*** ** Support max. 4K@60Hz as specified in DisplayPort 1.4. *** Supports 4K@60Hz as specified in HDMI 2.1.
    HDMI 1 x HDMI
    Display Port (s) 2 x DisplayPort
    VGA (s) 1 x VGA port
    USB (s) Rear USB (Total 4 ports) 2 x USB 3.2 Gen 1 ports (2 x Type-A) 2 x USB 2.0 ports (2 x Type-A) Front USB (Total 7 ports) 1 x USB 3.2 Gen 1 connector (suppports USB Type-C®) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports
    LAN Port (s) 1 x Intel 1Gb Ethernet ASUS LANGuard
    Wireless Communication module M.2 slot only (Key E, CNVi & PCIe)* * Wi-Fi module is sold separately.
    Supported Storage Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* Intel 13th & 12th Gen Processors M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel B760 Chipset M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports
    RAID Intel Rapid Storage Technology supports SATA RAID 0/1/5/10.
    Audio 3 x Audio jacks
    Internal I/O Ports Fan and Cooling related 1 x 4-pin CPU Fan header 2 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 connector (suppports USB Type-C®) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous 1 x Clear CMOS header 1 x Chassis Intrude header 2 x COM Port headers 1 x Front Panel Audio header (AAFP) 1 x COM debug header 1 x LPT header 1 x Mono-out header (with Amp IC) 1 x M.2 slot (Key E) 1 x SMBUS header 1 x Speaker header 1 x 10-1 pin System Panel header
    TPM (Trusted Platform Module ) 1 x SPI TPM header (14-1pin)
    Special Features ASUS Q-Design - Q-DIMM - Q-LED Core - Q-Slot ASUS EZ DIY - Box Headers Bespoke Motherboard Design & Business Focused Features - ASUS Self Recovering BIOS - ASUS Event Log - ASUS Commercial BIOS kit* - Anti-Moisture Coating - 24/7 Reliability - Overcurrent Protection
    Bundled Software ASUS Exclusive Software IT Management software supported - ASUS Control Center Express (ACCE)
    Manufacturing Warranty 3 years

    Description

    ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard

    The ASUS PRO B760M-C-CSM is a 13th gen micro-ATX motherboard designed for business use. It supports Intel's LGA1700 socket, making it compatible with 13th Gen Intel Core processors as well as 12th Gen Intel Core, Pentium Gold, and Celeron processors. The motherboard features the Intel B760 chipset and supports up to 192GB of DDR5 memory with speeds up to 6200(OC). It has four DIMM slots with support for dual-channel memory architecture and Intel Extreme Memory Profile (XMP). The Pro B760M-C-CSM provides multiple connectivity options, including 2 x DisplayPort, 1 x VGA port, and 1 x HDMI port. It offers expansion slots such as 1 x PCIe 4.0/3.0 x16 and 2 x PCIe 3.0 x1 for additional devices. Storage options include 2 x M.2 slots and 4 x SATA 6Gb/s ports, and it also features 1 x Intel 1Gb Ethernet port for network connectivity. The motherboard offers various USB ports, audio support with a Realtek 7.1 Surround Sound High Definition Audio CODEC, and comes with ASUS Q-Design features for easy installation and maintenance. It is designed with business-focused features like ASUS Self Recovering BIOS, ASUS Event Log, and 24/7 reliability. The ASUS PRO B760M-C-CSM is a reliable and feature-rich motherboard suitable for business users in need of a compact form factor.

    Write a review

    Please login or register to review
    Tags:

    What is the price of ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard in Bangladesh?

    The latest price of ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard in Bangladesh is 19,350৳ You can buy the ASUS PRO B760M-C-CSM 13th Gen Micro-ATX Motherboard at best price from our website or visit any of our showrooms.
