Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard

Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
New Save: 300৳
Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard
0 reviews - Write a review
  • Price: 20,200৳
  • Regular Price: 20,500৳
  • Stock : In Stock
  • Brand: Asus
  • Model: B650M-AYW WIFI

    • Model: B650M-AYW WIFI

    Chipset: AMD B650 Chipset

    Software Features: ASUS Exclusive Software

    Warranty: 3 Years

    Add to Cart
    Buy Now
    Add to Wish List Add to Compare

    অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে। হটলাইনঃ 09644-217088

    NEW! Since Journal 3.2, the much improved T.A.B (Tabs Accordion Blocks) system supports the page builder inside the tab content. Unlimited Blocks, Tabs or Accordions with any HTML content or the builder interface (supporting custom rows/columns/modules) can be assigned to any individual product or to certain groups of products, like entire categories, brands, products with specific options, attributes, price range, etc.

    You can indicate any criteria via the advanced product assignment mechanism and only those products matching your criteria will display the modules.

    Also, any module can be selectively activated per device (desktop/tablet/phone), customer login status and other criteria. Imagine the possibilities.

    Asus B650M-AYW WIFI DDR5 Micro-ATX Motherboard

    Specification:

    Model
    B650M-AYW WIFI
    CPU
    AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors*
    * Refer to https://www.asus.com/support/download-center/ for CPU support list.
    Chipset
    AMD B650 Chipset
    Memory
    2 x DIMM slots, max. 96GB, DDR5 Supports up to 8000+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC Un-buffered DIMM*
    Dual Channel Memory Architecture
    Supports AMD Extended Profiles for Overclocking (EXPO™)
    OptiMem II
    * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.
    * Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function.
    Graphics
    1 x HDMI™ port**
    * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.
    ** Supports 4K@60Hz as specified in HDMI 2.1.
    Expansion Slots
    AMD Ryzen™ 9000 & 7000 Series Desktop Processors*
    1 x PCIe 4.0 x16 slot (supports x16 mode)
    AMD Ryzen™ 8000 Series Desktop Processors
    1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**
    AMD B650 Chipset
    1 x PCIe 4.0 x16 slot (supports x4 mode)
    * Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).
    ** Specifications vary by CPU types.
    - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.
    Storage
    Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
    AMD Ryzen™ 9000 & 7000 Series Desktop Processors
    M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
    M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
    AMD Ryzen™ 8000 Series Desktop Processors
    M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
    M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4/x2 mode)**
    AMD B650 Chipset
    4 x SATA 6Gb/s ports
    * AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/10 and SATA RAID 0/1/10.
    ** Specifications vary by CPU types.
    Ethernet
    1 x Realtek 2.5Gb Ethernet
    USB
    Rear USB (Total 8 ports)
    2 x USB 10Gbps ports (2 x Type-A)
    2 x USB 5Gbps ports (2 x Type-A)
    4 x USB 2.0 ports (4 x Type-A)
    Front USB (Total 7 ports)
    1 x USB 5Gbps connector (supports USB Type-C®)
    1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
    2 x USB 2.0 headers support 4 additional USB 2.0 ports
    Audio
    Realtek 7.1 Surround Sound High Definition Audio CODEC*
    - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
    - Supports up to 24-Bit/192 kHz playback
    Audio Features
    - Audio Shielding
    - Premium audio capacitors
    - Dedicated audio PCB layers
    * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
    Back Panel I/O Ports
    2 x USB 10Gbps ports (2 x Type-A)
    2 x USB 5Gbps ports (2 x Type-A)
    4 x USB 2.0 ports (4 x Type-A)
    1 x HDMI™ port
    1 x Wi-Fi Module
    1 x Realtek 2.5Gb Ethernet port
    3 x Audio jacks
    Internal I/O Connectors
    Fan and Cooling related
    1 x 4-pin CPU Fan header
    2 x 4-pin Chassis Fan headers
    Power related
    1 x 24-pin Main Power connector
    1 x 8-pin +12V Power connector
    Storage related
    2 x M.2 slots (Key M)
    4 x SATA 6Gb/s ports
    USB
    1 x USB 5Gbps connector (supports USB Type-C® )
    1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
    2 x USB 2.0 headers support 4 additional USB 2.0 ports
    Miscellaneous
    3 x Addressable Gen 2 headers
    1 x Clear CMOS header
    1 x COM Port header
    1 x Front Panel Audio header (F_AUDIO)
    1 x S/PDIF Out header
    1 x 10-1 pin System Panel header
    Special Features
    ASUS 5X PROTECTION III
    - DIGI+ VRM
    - LANGuard
    - Overvoltage Protection
    - Safeslot Core+
    - Stainless-Steel Back I/O
    ASUS Q-Design
    - M.2 Q-Latch
    - Q-DIMM
    - Q-LED Core
    - Q-Slot
    ASUS Thermal Solution
    -  M.2 heatsink
    -  VRM heatsink design
    Aura Sync
    - Addressable Gen 2 headers
    Software Features
    ASUS Exclusive Software
    Armoury Crate
    - Aura Creator
    - Aura Sync
    - Fan Xpert 2+
    - Power Saving
    - Two-Way AI Noise Cancellation
    AI Suite 3
    - TurboV EVO
    - DIGI+ VRM
    - PC Cleaner
    ASUS CPU-Z
    Norton 360 Deluxe (60 Days Free Trial)
    WinRAR (40 Days Free Trial)
    UEFI BIOS
    ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    - ASUS UEFI BIOS EZ Mode
    BIOS
    256 Mb Flash ROM, UEFI AMI BIOS
    Manageability
    WOL by PME, PXE
    Accessories
    Cables
    2 x SATA 6Gb/s cables
    Miscellaneous
    1 x ASUS Wi-Fi moving antenna
    1 x I/O Shield
    1 x M.2 Rubber Package
    1 x Screw Package for M.2 SSD
    Documentation
    1 x Quick start guide
    Operating System
    Windows® 11, Windows® 10 64-bit
    Form Factor
    micro-ATX Form Factor
    9.6 inch x 8.7 inch ( 24.4 cm x 22.1 cm )


    Description:

    • Ready for Advanced AI PC: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications
    • AM5 Socket for AMD Ryzen™ Desktop Processors
    • Ultrafast Connectivity: PCIe 5.0 M.2 slot, Realtek 2.5Gb Ethernet, Wi-Fi 6, rear USB 10Gbps ports, front USB 5Gbps Type-C®
    • ASUS OptiMem II: Careful routing of traces and vias, plus ground layer optimizations to preserve signal integrity for improved memory overclocking
    • Comprehensive Cooling: VRM heatsink, M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+
    • Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware
