AMD Ryzen 5 9600X AM5 Desktop Gaming Processor (Chinese Edition)

Specification

AMD Ryzen 5 9600X AM5 Desktop Gaming Processor (Chinese Edition)

The AMD Ryzen 5 9600X is a powerful desktop gaming processor built with the newest Granite Ridge AM5 architecture and Zen 5 cores. With six CPU cores and twelve threads, this processor can handle demanding gaming and multitasking situations with ease. With a base speed of 3.9 GHz and a maximum boost clock of up to 5.4 GHz, it performs quickly. To ensure efficiency and power, the processor is based on TSMC's cutting-edge 4nm FinFET technology for the CPU cores and 6nm FinFET for the I/O die. With its 480 KB L1 cache, 6 MB L2 cache, and sizable 32 MB L3 cache, it improves system responsiveness and provides fast access to frequently used data. Supporting DDR5 memory, the Ryzen 5 9600X may reach speeds of up to DDR5-5600 depending on configuration and has a maximum capacity of 192 GB across two channels. Additionally, it offers an additional degree of data integrity dependability with ECC support—that is, if the motherboard is compatible with it. It is a flexible option for both gaming and content creation thanks to the integrated AMD RadeonTM Graphics, which have two cores running at 2200 MHz and compatibility with USB Type-C DisplayPort Alternate Mode. Additional performance tuning options are available with the AMD Ryzen 5 9600X AM5 Gaming Processor with support for AMD EXPO Memory Overclocking Technology and AMD Ryzen Technologies. To ensure quick data transfer and extension capabilities, it uses PCIe 5.0 with 28 native lanes and additional usable lanes depending on the motherboard. It is compatible with a broad range of chipsets, including A620, X670E, X670, B650E, B650, X870E, and X870. A maximum operating temperature of 95°C and a default TDP of 65W characterize the Ryzen 5 9600X, which is designed for efficiency and long-term performance under load.
